IGMP
IGMPv1/v2/v3
Mirroring
بله
QoS
Traffic shaping on the outbound interface, Traffic shaping for port queues, Traffic policing, PQ scheduling, PQ WRR scheduling, WDRR scheduling, PQ WDRR scheduling, WRR scheduling, Tail drop, MQC, Matching the simple fields of packets, ACL-based traffic classification, Modifying the simple fields of a packet, Traffic policing (CAR), Traffic mirroring, Traffic filtering, Changing packet priorities
STP
STP (802.1D), RTSP (802.1w), MSTP (802.1s)
VLAN
4094
استانداردها
IEEE 802.11ad
اقلام همراه
دفترچه راهنما
امنیت
ARP Security (ARP packet rate limiting, ARP anti-spoofing, Association between ARP and STP, Dynamic ARP Inspection, Static ARP Inspection, Egress ARP Inspection), IP Security (ICMP attack defence, IPSG for IPv4, IPSG for IPv6), Local attack defence (CPU attack defence), MFF, DHCP snooping (Option 82 function, Dynamic rate limiting for DHCP packets), Attack defence (Defence against malformed packet attacks, Defence against UDP flood attacks, Defence against TCP SYN flood attacks, Defence against ICMP flood attacks, Defence against packet fragment attacks, Local URPF)
تعداد پورت
28 عدد
توضیحات مدیریت
Port Mirroring, sFlow, LLDP-MED extended TLV, LLDP, NTP function, EasyDeploy client, RMON
جدول آدرس مک
32896
سایر مشخصات
پشتیبانی کامل پروتکلهای لایه 2 سوئیچینگ و محدود پروتکلهای لایه 3 روتینگ (استاتیک، RIP، OSPF)
سرعت انتقال
Switching Capacity: 336 Gbps\r\nForwarding Performance: 42Mpps
ظرفیت سوییچینگ
336 گیگابیت بر ثانیه
قابلیتهای آداپتور شبکه
نشانگر LED
قابلیتهای سوییچ
برنامهریزی و مدیریت
کنترل دسترسی
Standard IPv4 ACL, Advanced IPv4 ACL, Standard IPv6 ACL, Advanced IPv6 ACL, Layer 2 ACL, User Group ACL, User-defined ACL, User Group IPv6 ACL\r\nNumber of ACL rules: 2432 shared by IACL and EACL (the L2IPv4 in IACL is 1216)\r\nNumber of ACLv6 rules: IACL(VACL)/EACL:1216/2432
گواهینامهها
RoHS, REACH, WEEE
منبع تغذیه
داخلی
نوع پورتها
24x10/100/1000BASE-T ports, 4xGE SFP ports
نوع سوییچ
10/100/1000 مگابیت بر ثانیه
وزن
3000 گرم
