Antenna
4x external
Button
WPS Button, Reset Button, LED Button, Power Button
Dimensions ( W x D x H )
6.4x 3.4 x 1.6 in. (163 x 86 x 40mm)
Frequency
2.4GHz & 5GHz(11ac)
HARDWARE FEATURES
IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Input power
100-240V~50/60Hz
Interface
1x 10/100/1000M Ethernet Port (RJ45)
Others
FCC, RoHS
Plug Type
US
Ports
1 Gigabit Ethernet Port
Power Consumption
12W（max power consumption）
Reception Sensitivity
5GHz： 11a 6Mbps:-96dBm@10% PER 11a 54Mbps: -78dBm@10% PER 11ac HT20 mcs8: -69dBm@10% PER 11ac HT40 mcs9: -66dBm@10% PER 11ac HT80 mcs9: -63dBm@10% PER 2.4GHz 11g 54M: -79dBm@10% PER 11n HT20 mcs7: -77dBm@10% PER 11n HT40 mcs7: -74dBm@10% PER
Signal Rate
5GHz:Up to 1733Mbps 2.4GHz:Up to 800Mpbs
Transmission Power
<20dBm(2.4GHz) <23dBm(5GHz)
Wireless
Range Extender/Access Point
WIRELESS FEATURES
IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
Wireless Functions
Wireless Statistic Concurrent Mode boost both 2.4G/5G WiFi band High Speed Mode for great speed for HD Gaming and video Access Control LED Control Domain Login Function
Wireless Security
64/128-bit WEP WPA-PSK / WPA2-PSK
