Antenna
2 External Dual Band Antennas
Button
Power On/Off Button, WPS/Wi-Fi Button, RESET Button
DHCP
Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Dynamic DNS
DynDns, NO-IP
External Power Supply
12V/1.5A
Frequency
2.4GHz and 5GHz (not Supports DFS)
Interface
4 10/100/1000Mbps RJ45 LAN Ports, 1 SC/APC XPON Port, 1 RJ11 FXS Port
MANAGEMENT
Web Based Configuration(HTTP), Remote management, Command Line Interface, SSL for TR-069, Web Based Firmware Upgrade, Diagnostic Tools, OMCI
Mesh Technology
WPA EasyMesh, TP-Link OneMesh
Port Forwarding
Virtual Server, Port Triggering, DMZ, ALG, UPnP
Security
NAT Firewall, Access Control, MAC/IP/URL Filtering, IP and MAC Address Binding, Defense “Denial of Service (DoS), SYNFlooding, Ping of Death”
Signal Rate
867Mbps at 5GHz, 300Mbps at 2.4GHz
SOFTWARE FEATURES
Hardware QoS
Transmit Power
2.4GHz: 26dBm(EIRP), 5GHz: 27dBm(EIRP)
VPN Pass-Through
PPTP, L2TP, IPSec Pass-through
WIRELESS FEATURES
IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
Wireless Functions
Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Schedule
Support 2.4GHz and 5GHz Wireless Schedule
Wireless Security
WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
