Advanced Functions
IP/MAC/URL/WEB Filtering
BASIC FUNCTIONS
Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable
Button
Reset Button
DHCP
DHCP Server/Client, DHCP Address Reservation
Dimensions ( W x D x H )
11.6 x 7.1 x 1.7in. (294 x 180 x 44mm) 13-inch / 19-inch Standard Rack-Mount Width, 1U Height
Forwarding
Virtual Server, Port Triggering, DMZ
HARDWARE FEATURES
IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS
IGMP
IGMP Proxy/IGMP Snooping
Interface
1 Fixed 10/100 Ethernet WAN Port 1 Fixed 10/100 Ethernet LAN Port 3 Changeable 10/100 Ethernet WAN/LAN Ports
LED
PWR, SYS, WAN, LAN, WAN/LAN
Load Balance
Policy Routing, Link Backup
MAC Clone
Modify WAN/LAN MAC Address
NAT
One-to-One NAT, Multi-Nets NAT
Network Media
10BASE-T: UTP category 3, 4, 5 cable (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m)
Performance
30K
Switch Setting
Port Mirror, Rate Control, Port Configuration, Port VLAN
