Advanced Functions
• Multi-Link Operation (MLO) • 320 MHz Channel • 4K-QAM • Multi-RUs • EasyMesh-Compatible • Works with Alexa and Google Assistant • IoT Network
Buttons
• Power On/Off Button • Wi-Fi On/Off Button • LED Button • WPS Button • Reset Button
EasyMesh
Compatible with EasyMesh
Ethernet ports
• 1× 2.5 Gbps WAN • 4× 2.5 Gbps LAN
Guest Network
• 1× 6 GHz Guest Network • 1× 5 GHz Guest Network • 1× 2.4 GHz Guest Network
HARDWARE
High-Performance CPU
Parental Controls
HomeShield Parental Controls Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports
Power
12 V ⎓ 3.3 A
Security
• SPI Firewall • Access Control • IP & MAC Binding • Application Layer Gateway• HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner
Service Kit
HomeShield Learn More>
Software
• IPv4 • IPv6
USB Support
1× USB 3.0 • Supported Partition Formats: NTFS, exFAT, HFS , FAT32 • Supported Functions: FTP Server Media Server Samba Server
VPN client
• Open VPN Client • PPTP VPN Client • L2TP VPN Client
VPN Server
• OpenVPN Server • PPTP VPN Server • L2TP VPN Server
WiFi Capacity
High Tri-Band Allocate devices to different bands for optimal performance 2×2 MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple clients Airtime Fairness Improves network efficiency by limiting excessive occupation DFS Access an extra band to reduce congestion 6 Streams Connect your devices to more bandwidth
WiFi Encryption
• WPA • WPA2 • WPA3 • WPA/WPA2-Enterprise (802.1x)
WiFi Range
4 Bedroom Houses 6× Optimally Positioned Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas Beamforming Concentrates wireless signal strength towards clients to expand WiFi range High-Power FEM Improves transmission power to strengthen signal coverage
Wireless
BE9300 • 6 GHz: 5760 Mbps (802.11be) • 5 GHz: 2880 Mbps (802.11be) • 2.4 GHz: 574 Mbps (802.11ax)
Working Modes
• Router Mode • Access Point Mode
