Advanced Functions
• Multi-Link Operation (MLO) • 160 MHz Channel • 4K-QAM • Multi-RUs • Works with Alexa and Google Assistant
Buttons
1× Reset Button 1× WPS
Guest Network
1× 5 GHz Guest Network 1× 2.4 GHz Guest Network Effective Time Bandwidth Control
HARDWARE
• 2× 2.5 Gbps *Per Deco Unit Supports WAN/LAN auto-sensing
Parental Controls
HomeShield Parental Controls Youtube Restriction SafeSearch Custom Profiles Professional Content Filter Library Family Time Bedtime Off Time Time Rewards Family Online Time Ranking Pause the Internet Weekly and Monthly Reports
Protocols
IPv4 IPv6
Quality of Service
HomeShield QoS QoS by Device
Security
SPI Firewall Access Control HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner
Service Kits
HomeShield Learn More>
Software
• Reboot Schedule • Tapo/Kasa Onboarding • IoT network & Device Isolation • Static Routing Function • Node/Band Connection Preference
VPN client
• OpenVPN Client • PPTP VPN Client • L2TP/IPSec VPN Client
VPN Server
• OpenVPN Server • PPTP VPN Server • L2TP/IPSec VPN Server
WAN Types
Dynamic IP Static IP PPPoE PPTP L2TP
WiFi Capacity
Very High Dual-Band Distribute devices to different bands for optimal performance OFDMA Simultaneously communicates with multiple WiFi 7 clients 4 Streams More than enough bandwidth for connected devices
WiFi Encryption
WPA-Personal WPA2-Personal WPA3-Personal
WiFi Range
Broader Whole Home Coverage TP-Link Mesh Technology Optional Ethernet backhaul work together to link Deco units to provide seamless coverage AI-Driven Mesh Intelligently learns the network environment to provide ideal Wi-Fi unique to your home 4× High-Performance Antennas (Internal) Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Speeds
BE3600 5 GHz: 2882 Mbps (802.11be) 2.4 GHz: 688 Mbps (802.11be)
Wireless
Wi-Fi 7 IEEE 802.11be/ax/ac/n/a 5 GHz IEEE 802.11be/ax/n/b/g 2.4 GHz
Working Modes
Router Mode Access Point Mode
