Bandwidth
20/40/80 MHz channels tunable to 5 MHz increments for Mimosa SRS; Tunable to standard WiFi channels for WiFi Interop
Brand
MIMOSA
Connector Type
RP-SMA (x2)
Dimensions
Depth 44 mm (1.73"), Height 188.4 mm (7.42"), Width 65 mm (2.56")
Frequency Range
*new* US/FCC 5600-5650 MHz support FCC DFS (U-NII-2a, U-NII-2c) availability pending certification, PTMP: 4900-6400 MHz***, PTP: 4900-6400 MHz, Restricted by country of operation
Gigabit Ethernet
10/100/1000-BASE-T
Management Services
Mimosa cloud monitoring and management, SNMPv2 & Syslog legacy monitoring, HTTPS, HTML 5 based Web UI
Max Power Consumption
9.2 W
Max Throughput
PTP/PTMP: 700 Mbps IP (866 Mbps PHY)
MIMO 5 GHz
2×2:2 MIMO OFDM up to 256 QAM
Mount materials
Single pole strap
Operating Altitude
4420 m (14501') maximum
OPERATING HUMIDITY
5 to 100% condensing
OPERATING TEMPERATURE
-40°C to 55°C (-40°F to 131°F)
Outdoor Ingress Protection Rating
IP55
PoE Power Supply
Passive POE compliant, 48-56 V Power over Ethernet supply (Not Included)
QoS
Supports 4 pre-configured QoS levels
Safety
UL/EC/EN/ 60950-1 CSA-22.2
Security
WPA2 Mimosa 802.1x Client**
Sensitivity ( MCS 0 )
-87 dBm @ 80 MHz, -90 dBm @ 40 MHz, -93 dBm @ 20 MHz, 20W
Shock & Vibration
ETS 300-019-2-4 class 4M5
Smart Spectrum Management
Active scan monitors/logs ongoing RF interference across channels (no service impact) Dynamic auto-optimization of channel and bandwidth use
System Power Method
Passive PoE (24-56 VDC)
Weight
295 grams (10.4 oz)
Wireless Protocols
WiFi Interop Mimosa SRS
