استانداردهای حافظه
11th Generation Intel Core i9/i7/i5 processors: Support for DDR4 3200/3000/2933/2666/2400/2133 MHz مگاهرتز
پردازندههای پشتیبانی شده
11th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors\r\n10th Generation Intel Core i9 processors / Intel Core i7 processors / Intel Core i5 processors / Intel Core i3 processors/ Intel Pentium processors / Intel Celeron processors\r\nLimited to processors with 4 MB Intel Smart Cache, Intel Celeron G5xx5 family.\r\n L3 cache varies with CPU\r\n
پورت LAN
یک عدد
تعداد اسلات حافظه
چهار عدد
توضیحات تکمیلی پورتها
یک عدد PS/2 mouse port\r\nیک عدد PS/2 Keyboard port\r\nیک عدد D-Sub port\r\nیک عدد D-Sub port\r\nچهار عدد USB 3.2 Gen 1 ports\r\nدو عدد USB 2.0/1.1 ports\r\nیک عدد RJ-45 port\r\nسه عدد audio jacks
توضیحات تکمیلی تمامی پورتهای USB مادربرد
-شش عدد: USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)\r\n- هشت عدد USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through the internal USB headers)
توضیحات حافظه
11th Generation Intel Core i9/i7/i5 processors\r\n Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules\r\n 10th Generation Intel Core i9/i7 processors:\r\n Support for DDR4 2933/2666/2400/2133 MHz memory modules\r\n 10th Generation Intel Core i5/i3/Pentium/Celeron processors:\r\n Support for DDR4 2666/2400/2133 MHz memory modules\r\n 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory\r\n Dual channel memory architecture\r\n Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)\r\n Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\n Support for Extreme Memory Profile (XMP) memory modules\r\n
چیپست
Intel B560
سایر توضیحات بایوس
یک عدد 256 Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
سایر توضیحات مربوط به اسلاتها
یک عدد PCI Express x16 slot, running at x16 (PCIEX16)\r\n(The PCIEX16 slot conforms to PCI Express 4.0 standard.)\r\nیک عدد PCI Express x1 slot (PCIEX1)\r\n(The PCIEX1 slot conforms to PCI Express 3.0 standard.)
فرم فاکتور
microATX
کارت شبکه LAN
Realtek GbE LAN chip (1 Gbit/100 Mbit)
کارت صدا
Realtek Audio CODEC
کانکتورهای برق
کانکتور برق 8 پین ATX
مجموع کانکتور فن
دو عدد
نوع اسلات M.2
Key M
نوع سوکت پردازنده
Intel LGA 1200
هدر USB 2.0
سه عدد
