استانداردهای حافظه
5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 // 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 // 5400(O.C.) / 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 مگاهرتز
برد تغذیه
14 فاز
پردازندههای پشتیبانی شده
AMD Socket AM4, support for : AMD Ryzen 5000 Series / 3rd Generation AMD Ryzen processors / 3rd Generation AMD Ryzen with Radeon Graphics processors
تعداد مسیرهای PCI Express
24 مسیر
توضیحات تکمیلی پورتها
1 عدد HDMI port\r\n2 عدد SMA antenna connectors (1T1R)\r\n3 عدد USB 3.2 Gen 1 ports\r\n1 عدد USB Type-C port, with USB 3.2 Gen 2 support\r\n2 عدد USB 3.2 Gen 2 Type-A ports (red)\r\n6 عدد USB 2.0/1.1 ports\r\n1 عدد RJ-45 port\r\n1 عدد optical S/PDIF Out connector\r\n5 عدد audio jacks
توضیحات تکمیلی تمامی پورتهای USB مادربرد
CPU:\r\n3 عدد USB 3.2 Gen 1 ports on the back panel\r\n1 عدد USB 3.2 Gen 2 Type-A port (red) on the back panel\r\nChipset:\r\n1 عدد USB Type-C port on the back panel, with USB 3.2 Gen 2 support\r\n1 عدد USB 3.2 Gen 2 Type-A port (red) on the back panel\r\n2 عدد USB 3.2 Gen 1 ports available through the internal USB header\r\n2 عدد USB 2.0/1.1 ports on the back panel\r\nChipset+2 USB 2.0 Hubs:\r\n8 عدد USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
توضیحات تکمیلی قسمت ذخیرهسازی (Storage)
1 عدد M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:\r\n3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs\r\n3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs\r\n1 عدد M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:\r\nsupport PCIe 3.0 x4/x2 SSDs\r\n6 عدد SATA 6Gb/s connectors, integrated in the Chipset:\r\nSupport for RAID 0, RAID 1, and RAID 10
توضیحات تکمیلی هدرها
1 عدد CPU fan header\r\n1 عدد water cooling CPU fan header\r\n4 عدد system fan headers\r\n2 عدد system fan/water cooling pump headers\r\n1 عدد CPU cooler LED strip/RGB LED strip header\r\n2 عدد addressable LED strip headers\r\n2 عدد RGB LED strip headers\r\n1 عدد front panel header\r\n1 عدد front panel audio header\r\n1 عدد USB 3.2 Gen 1 header\r\n2 عدد USB 2.0/1.1 headers\r\n2 عدد temperature sensor headers\r\n1 عدد Thunderbolt header
توضیحات کارت صدا
High Definition Audio\r\n2/4/5.1/7.1-channel\r\nSupport for S/PDIF Out
حافظه
۴ اسلات DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory\r\nAMD Ryzen 5000 series Processors:\r\nSupport for DDR4 5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules\r\n3rd Gen AMD Ryzen Processors:\r\nSupport for DDR4 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules\r\n3rd Gen AMD Ryzen with Radeon Graphics processors:\r\nSupport for DDR4 5400(O.C.) / 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules\r\nDual channel memory architecture\r\nSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules\r\nSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules\r\nSupport for Extreme Memory Profile (XMP) memory modules
دکمهها
Q-Flash Plus button
دکمهها، سوییچها و جامپرها
Clear CMOS jumper
سایر توضیحات بایوس
256Mbit flash\r\nUse of licensed AMI UEFI BIOS\r\nPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
سایر توضیحات کارت گرافیک
Integrated in the 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors:\r\n1 عدد HDMI port, supporting a maximum resolution of 4096x2160@60 Hz\r\nMaximum shared memory of 16 GB
سایر توضیحات مربوط به اسلاتها
1 مسیر PCI Express x16 slot (PCIEX16), integrated in the CPU:\r\n3rd Generation AMD Ryzen processors support PCIe 4.0 x16 mode\r\n3rd Generation AMD Ryzen with Radeon Graphics processors support PCIe 3.0 x16 mode\r\n1 مسیر PCI Express x16 slot (PCIEX4), integrated in the Chipset:\r\nSupporting PCIe 3.0 x4 mode\r\n1 مسیر PCI Express x16 slot (PCIEX2), integrated in the Chipset:\r\nSupporting PCIe 3.0 x2 mode\r\n2 مسیر PCI Express x1 slots
قابلیتهای مادربورد
نقاط کنترل ولتاژ
کارت شبکه LAN
Realtek 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)
کارت صدا
Realtek ALC1220-VB codec
کانکتورهای برق
کانکتور برق اصلی 24 پبن ATX
نوع اسلات M.2
PCI-E 3.0 x4
نوع تخصیص مسیر
1 مسیر PCI Express x16 slot (PCIEX16)\r\n1 مسیر PCI Express x16 slot (PCIEX4)\r\n1 مسیر PCI Express x16 slot (PCIEX2)
