802.1Q Support
VLAN Group- Max 4,094 Static VLAN Groups
Voice VLAN
Forwarding Mode
Store and forward
Jumbo Frame
9K
MAC Address Table
8K
VLAN
Max 4094 Static Groups, Voice VLAN
استانداردهای شبکه
IEEE 802.3 Ethernet
IEEE 802.3i 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 10000Base-T Gigabit Ethernet
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3z Gigabit Ethernet 1000Base-SX/LX IEEE 802.3ad Link Aggregation (Trunking)
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) IEEE 802.1Q VLAN Tagging
IEEE 802.1ab Link Layer Discovery Protocol (LLDP) IEEE 802.1p Quality of Service
IEEE 802.1X RADIUS Access Control
IEEE 802.3az Energy Efficient Ethernet
ظرفیت سوییچ
20Gbps
مدیریت
Wireless AP Controller, ezMaster Network Management Software, Web GUI, CLI, SNMP, RMON, HTTPS, Dual Image
مقدار حافظه
Flash Memory:4MB
منبع تغذیه
PoE capable port:1-8 (802.3af only)
Max Power per port:up to 15.4w per port
Total PoE budget:61.6W
Power Source:100 to 240 VAC 50/60Hz
نوع پورتها
10/100/1000 Base-T, POE+:8
10/100/1000 SFP Ports:2
وضعیت قرار گیری در رک
رومیزی-دسکتاپ
