AHD Camera
1080P@25/30, 720P@25/30fps
Alarm input
N/A
Analog Camera Input
4/8 Channel, BNC
Audio bit rate
64Kbps Per Channel
Audio Compression
AAC(only for the 1st channel), G.711A, G.711U, PCM
Audio In/Out
1/1, RCA
Audio Sample Rate
8KHz, 16 bit Per Channel
Backup Mode
USB Device/Network
CVBS Camera
PAL/NTSC
Dimensions
Cooper 1U, 197mm×192mm×41mm (7.8“×7.6”×1.6“)
HDCVI Camera
1080P@25/30fps, 720P@25/30fps
Interface
1 RJ-45 Port (100M)
Internal HDD
1 SATA Port, up to 6TB capacity
Interoperability
ONVIF 16.12, CGI Conformant
IP Camera Input
4CH: 4+1, each channel up to 2MP8CH: 8+2, each channel up to 5MP
Main Processor
Embedded Processor
Max. User Access
128 users
Multi-screen Display
When IP extension mode not enabled:4CH: 1/48CH: 1/4/8/9When IP extension mode enabled:4CH: 1/4/68CH: 1/4/8/9/16
Network Function
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter ,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.)
Operating System
Embedded LINUX
OSD
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Playback
4CH: 1/48CH: 1/4/9
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup selection, Digital Zoom
Power Consumption(without HDD)
<10W
Power Supply
DC12V/1.5A
Record Interval
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Record Mode
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Rate
Main Stream:4CH: All channel 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)8CH: the 1st channel 1080N/720P(1~25/30fps), others 1080N(1~12fps)/720P(1~15fps); 960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)Sub steram:4CH: CIF/QCIF (1~15fps)8CH: CIF/QCIF (1~7fps)
Resolution
1920×1080, 1280×1024, 1280×720, 1024x768
Search Mode
Time /Date, Alarm, MD and Exact Search (accurate to second)
Smart Phone
iPhone, iPad, Android
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Two-way Talk
Reuse audio in/out, RCA
USB
2 USB 2.0
Video Bit Rate
32Kbps ~ 4096Kbps Per Channel
Video Compression
H.264
Video Detection
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
