ابعاد
14X12X10mm ميليمتر
اقلام همراه
Installation Guide, Windows decoder 1-user license, Mounting bracket, Cable gasket, Resistorx T20 L-key, Drill template
امنیت
Password protection, IP address filtering, HTTPSa encryption, IEEE 802.1Xa network access control, Digest authentication, User access log, Centralized Certificate Management
پروتکلها
IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnPTM, SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
حداقل نور
Color: 0.25 lux.B/W: 0.05 lux.HDTV 1080p 50/60 fps
رزولوشنهای تصویر
1920x1080
سایر قابلیت ها و توضیحات
> HDTV 1080p video quality > Outdoor-ready and IK10-rated > Remote zoom and focus > WDR - Forensic Capture > OptimizedIR illumination > Axis’ Zipstream technology
سایز حسگر تصویر
1.28
فاصله کانونی
3-10.5mm
فرمتهای ویدیویی
H.264 Baseline, Main and High Profile (MPEG-4 Part 10/AVC) Motion JPEG
کارت حافظه قابل پشتیبانی
512MB RAM.256MB Flash
مدیریت
AXIS Camera Companion, AXIS Camera Station, Video management software from Axis’ Application Development Partners available
مشخصات اتصال
Progressive scan RGB CMOS 1/2.8
منبع تغذیه
Power over Ethernet IEEE 802.3af/802.3at Type 1 Class 3, max 10.8 W, typical 3.9 W
میزان بزرگنمایی اپتیکال
3Xبرابر
میزان بزرگنمایی دیجیتال
8X برابر
نوع اتصال
باسيم (LAN)
نوع حسگر تصویر
CMOS
نوع لنز
Varifocal
وزن
770gr گرم
