اتصالات
HDMI x2 RGB / VGA x1 DisplayPort x1 DVI x1 Audio x1 PC audio(3.5 mm), x1 Shared RCA audio (L+R) CVBS x1 (Share with component Y) YPbPr x1 RS232 x1 IR Pass Thru x1 OPS x1
اندازه پنل
55" (54.64") 1209.6(H) x 680.4 (V) (54.64” diagonal)
تکنولوژی پنل
TFT LCD Module with LED Backlight
رزولیشن
1080*1920
زاویه دید
H = 178, V = 178
زمان پاسخگویی
12ms
شدت نور
500nits
شرایط محیطی
5- 40°C (landscape) 5- 35°C (portrait) Humidity 20% ~ 80% non-condensing
صدا
10w *2x
کنترل
PICTURE: POWER, MUTE, INPUT, VOL -/+, UP, DOWN, MENU Picture style, Restore style, Backlight, Colour, Sharpness, Noise reduction, MPEG artifact reduction, Digital Crystal Clear, Advanced, Game or computer, Format and edges, Input resolution SOUND: Sound style, Restore style, Bass, Treble, Balance, Surround mode, Audio Out, Advanced TILING: Enable, H monitors, V monitors, Position, Frame Comp. GENERAL SETTINGS: Menu language, Monitor ID, Eco mode, Auto search, Clock, Scheduling, Sleep timer, CEC, Auto adjust, Locak KB lock, RC lock, Pixel shift, Smart power, Wake on lan, Switch on state, Light sensor, LED, Switch on delay, Logo, APM, Information OSD, DisplayPort Ver., Cooling fan, Network control port,Factory settings. NETWORK SETTINGS: View network settings, Network configuration, Static IP Configuration, Digital Media Renderer-DMR, Network name
لوازم همراه
PACKAGE CONTENTS 1. CDX5552 LCD Monitor 2. Remote Control with batteries 3. User manual CD wizard 4. Quick Start Guide 5. Power Cables 6. VGA cable 7. RS232 cable 8. IR sensor cable *Actual content may differ from market to market
منبع نیرو
100-240 VAC +/- 10% Wide Range, 50-60Hz +/-3 Hz
نسبت تفکیک پذیری
1400:1
