ابعاد
22.3cm x 19.6cm
اسلات M.2
1x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD
اسلات ها
1x PCI Express x16 slot, supporting PCIe 4.0 and running at x161x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
پردازنده قابل پشتیبانی
14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
پورت D-Sub
1x
پورت Gigabit Ethernet
1x
پورت HDMI
1x
پورت PS/2 مشترک موس و کیبورد
1x
پورت SATA 6Gb/s
4x SATA 6Gb/s connectors
پورت USB 2.0
4x
پورت USB 3.2
2x
پورت های خروجی
1x HDMI Port1x D-Sub port
پیکربندی
دوکاناله
تراشه شبکه
Realtek® GbE LAN chip
تراشه صدا
Realtek® Audio CODEC
تعداد اسلات
2 عدد
تعداد سوکت
1 عدد
جک 3.5 میلیمتری
3x
چیپست
Intel H610
حداکثر حافظه قابل پشتیبانی
128 گیگابایت
سایر کانکتورهای داخلی
1x 8-pin ATX 12V power connector1x CPU fan header1x RGB LED strip header1x front panel header1x front panel audio header1x Clear CMOS jumper1x 24-pin ATX main power connector1x serial port header1x Speaker header1x Chassis Intrusion header2x system fan headers1x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/ GC-TPM2.0 SPI V2 module only)
سوکت
LGA 1700
فرکانس حافظه
13th Generation Intel® Core™ i5/i3 and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors: Support for DDR5 4800/4400 MT/s memory modules14th and 13th Generation Intel® Core™ i9/i7 Pocessors: Support for DDR5 5600/5200/4800/4400 MT/s memory modules
فرم فاکتور
Micro ATX Form Factor
کانکتورهای داخلی USB
2x USB 2.0/1.1 headers1x USB 3.2 Gen 1 header
نوع پلتفرم
Intel
نوع حافظه قابل پشتیبانی
DDR5
وضعیت محصول
اصل
