1
Max. Current:10A 250VAC
10
Mechanical life:≥2000,000 times
11
Contact Resistance:≤50mΩ
12
Insulation Resistance:≥1000mΩ
13
Contact material:Silver alloy
14
Mounting hole size:22mm
15
Torque: 5 ~ 14Nm
16
Dielectric Strength:AC 1000V 1 Minute
17
Total travel:1.5±0.5mm
18
Operating force:400±50gf
19
Insulation Resistance:DC 500V 100M Min
2
℃Operation temperature:-40℃~+80
20
Operation Pressure approx. 5N
21
Vibration Resistance 10 – 50Hz, 1.5mm Double Amplitude
22
Shock Resistance Detruction:O.F.>0.5N: 1000m/s2 (approx. 100g), O.F.≤0.5N: 400m/s2 (approx. 40g) Malfunction:O.F.>0.5N: 200m/s2 (approx. 20g), O.F.≤0.5N: 100m/s2 (approx. 10g)
23
Dielectric Strengh Between non-consecutive terminals 1,000Vrms, 50/60Hz for 1min Between non-current carrying metal parts and each terminal 1,500Vrms, 50/60Hz for 1min Between ground and each terminal 1,500Vrms, 50/60Hz for 1min
24
Max. Panel Thickness 0.394″ (10.0mm)
3
Voltage:25v-250v
4
LED voltage: 220VAC
5
Operation type:Momentary
6
Contact:1NO+1NC
7
Terminal type:Screw Terminal
8
Single gross weight:0.010 kg
9
Electrical life :≥50,000 times
