( )5/4,(-)8/7
Optional
Auto MDI-MDIX
Yes All Port
Bandwith
20Gb Internal Bandwidth
Cabling
10Base-TX:Cat 3 or above Cat.5 UTP(100m) POE=200M 100Base-TX:Cat 5 UTP(100m) POE=150M 1000Base-TX:Cat 6e UTP or Cat 6 UTP(120m) POE=150M
CASE
Metal Case
Console
Yes – Web & RS232 Layer2 Management (Telnet Support)
Dimension
176*128*54 mm
Fast RJ45 POE Port
N/A
Gigabit RJ45 POE Port
8 Port (Up To 90 Watt Per Port-Up to 200 Watt Max)
Gigabit SFP Uplink Port
2
IP Rating
IP51
LED
Ethernet Interfaces 1000 LNK/ACT (Orange), 10/100 LNK/ACT (Green) PoE Ethernet Interfaces PoE-in-Use (af/at-Red)
LED Panel
Data Activity, PoE Activity
MAC Table
64Kb
Main Board
Double Layer
Max POE Output
200 Watt
Mounting
Rackmount / desktop
MTBF
100K hrs min. MIL-HDBK-217F (25°)
Operation Temp
-15°C ~ 50°C / 10% ~ 90% RH
POE Port Control
Texas Instruments Chipset
Power
110~240V-AC
Processore Type SMIU
Realtek
Product Guarantee
3 Year Platinum Guarantee
Protocols
CSMA/CD
Radiation Electromagnetic
EN55016
Security
Port Security, Access IP List, SSH & HTTPS Login, IEE 802.1 X MAB (MAC Authentication Bypass) / Radius Server Authentication
Speed
Ethernet 10Mbps (half duplex), 20Mbps (full duplex); 10BASE-T: 14,880bps/port Fast Ethernet 100Mbps (half duplex), 200Mbps (full duplex); 100BASE-TX:14,8800bps/port Gigabit Ethernet 1000Mbps (half duplex), 2000Mbps (full duplex); 1000BASE-TX: 1488000bps/port
STANDARD
IEEE802.3x, IEEE802.3u, IEEE802.3az, IEEE802.3ab, IEEE802.3af, IEEE802.3at (Up to 30Watt), IEEE802.3bt
Storage Temp
-20°C ~ 60°C / 10% ~ 90% RH
Total Port
10 Ports
Transfer Pattern
Store & Forward
Web Language
English
Weight
625 g
