Access Control
Parental Control Local Management Control Host List Access Schedule Rule Management
Antenna
Three 5dBi external antennas
Button
WPS/Reset Button Wireless On/Off Switch Power On/Off Button
DHCP
Server, Client, DHCP Client List, Address Reservation
Dimensions ( W x D x H )
8.9*5.8*1.3in (225*148*33mm)
Environment
Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Guest Network
2.4GHz guest network 5GHz guest network
HARDWARE FEATURES
4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port 1 USB 2.0 port
MANAGEMENT
Access Control Local Management Remote Management
Others
CE, RoHS
Package Contents
AC1350 3G/4G Wireless Dual Band Router TL-MR3620 Power supply unit Ethernet Cable Quick Installation Guide
Power Supply
12VDC/1A
Protocols
IPv4 IPv6
SOFTWARE FEATURES
WMM, Bandwidth Control
USB Sharing
3G/4G sharing Samba(Storage) FTP Server Media Server Printer Server
VPN Pass-Through
PPTP L2TP IPSec
Wan Type
Dynamic IP/Static IP/PPPoE/ BigPond/ /L2TP(Dual Access) /PPTP(Dual Access)
WIRELESS FEATURES
IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2.4GHz
Wireless Security
WEP WPA\WPA2 WPA-PSK\WPA2-PSK
Wireless Speeds
450Mbps(2.4GHz) 867Mbps(5GHz)
