Approvals
FCC Part 15.407, IC RSS210, CE, ETSI 301 893/302 502
Bandwidth
Single or dual 20/40/80 MHz channels; Regulations vary by region
Brand
MIMOSA
Colocation Synchronization
1PPS GPS TX/RX synchronization for collocated cochannel radios; Adjustable up/downstream bandwidth ratio
Dimensions
241*139*76 mm
Dual Link Operation
2 independent dual-stream radios operating on non-contiguous frequencies; Automatic load balancing of traffic across 4 total MIMO streams with individual stream encoding up to 256 QAM
Enclosure Characteristics
Die-cast aluminum
Frequency Range
4.90–6.40 GHz
Gigabit Ethernet
10/100/1000-BASE-T
GPS Location
GNSS-1 (GPS GLONASS)
Low Latency
<1 ms in auto mode
Max Output Power
30 dBm
Max Power Consumption
20 W
Max Throughput
Up to 1.5 Gbps IP aggregate UL/DL (1.7 Gbps PHY)
MIMO 5 GHz
4×4:4 MIMO OFDM up to 256QAM
Operating Altitude
4,420 m (14,500’) maximum
OPERATING HUMIDITY
5 to 100% condensing
OPERATING TEMPERATURE
-40°C to 55°C (-40°F to 131°F)
Outdoor Ingress Protection Rating
IP67
PoE Power Supply
50 VDC passive Gigabit PoE injector
QoS
4 classes of QoS, with user configurable priority queuing, weighted fair queuing, MIR, CIR, and rate limiting
Safety
EN 62638-1, CAN/CSA C22.2 No. 62368-1
Security
128-bit AES PSK with hardware acceleration
Sensitivity ( MCS 0 )
-87 dBm @ 80 MHz, -90 dBm @ 40 MHz, -93 dBm @ 20 MHz
Shock Vibration
ETS 300-019-2-4 class 4M5
Smart Antenna Alignment
Mimosa management; SNMPv2 & Syslog legacy monitoring; HTTPS; HTML 5 based Web UI
Smart Spectrum Management
Active scan monitors/logs ongoing RF interference across channels (no service impact) Dynamic auto-optimization of channel and bandwidth use
System Lightning ESD Protection
6 kV
System Power Method
48 VDC passive isolated PoE injector
Weight
1.4 kg (3.1 lbs) without mount
Wind Survivability
200 km/h (125 mph)
Wireless Protocols
Fixed TDMA and TDMA-FD (Frequency Diversity) with 75:25, 67:33, or 50:50 traffic ratios with 2, 4, or 8 ms timeslots; Auto-TDMA
