10/100/1000 Ethernet ports
2
3G bands
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
3G Category
R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
Antenna gain dBi for 5 GHz
5.5
Architecture
ARM 64bit
Brand
MikroTik
CPU
IPQ-6010
CPU core count
4
CPU nominal frequency
auto (864 – 1800) MHz
DC jack input Voltage
18-57 V
LTE Category
12 (600Mbps Downlink, 150Mbps Uplink)
LTE FDD bands
1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz)
LTE TDD bands
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
Max Power Consumption
34 W
MTBF
Approximately 200'000 hours at 25C
Number of DC inputs
2 (DC jack, PoE-IN)
Operating System
RouterOS v7
PoE in
802.3af/at
PoE out
Passive PoE up to 57V
PoE-out ports
Ether2
Product Code
cAPGi-5HaxD2HaxD&EG12-EA
RouterOS license
4
Size of RAM
1 GB
Storage size
128 MB
Storage type
NAND
Tested ambient temperature
-40°C to 50°C
Wireless 2.4 GHz chip model
QCN-5022
Wireless 2.4 GHz Max data rate
574 Mbit/s
Wireless 2.4 GHz number of chains
2
Wireless 2.4 GHz standards
802.11a/n/ac/ax
Wireless 5 GHz generation
Wi-Fi 6
Wireless 5 GHz Max data rate
1200 Mbit/s
Wireless 5 GHz number of chains
2
